Gefran 1000 Panel, Front PID Temperature Controller, 1 Output Logic, Relay 24V ac/dc On-Off
Documente tehnice (Imaginile sunt cu titlu informativ. Va rugam sa consultati specificatiile tehnice.)
Specificatii
Marca
GefranTip iesire
Logic, Relay
Product Type
PID Temperature Controller
Numar iesiri
1
Maximum Current
5A
Temperatura maxima de lucru
50°C
Temperatura minima de lucru
0°C
Control Type
On-Off
Tensiune de alimentare maxima
24V ac/dc
Controlled Phases
3
Maximum Voltage
250V
Tip afisare
LED
Protectie IP
IP54
Lungime
48mm
Standards/Approvals
EN 61000-6-3, EN 61010-1, CE, EN 61000-6-2
Latime
96mm
Montare
Panel, Front
Input Type
0 to 20 mA, 4 to 20 mA, 10 to 50 Mv, 0 to 10 V, PT1000, 0 to 50 Mv
Series
1000
Panel Depth
100mm
Tara de origine
Italy
Detalii produs
Gefran 1000 Series
Suitable for use in manufacturing, chemical and pharmaceutical industries as well as food, packaging and even wood working machines. The Gefran 1000 series of Microprocessor Controllers supports thermocouple configuration to suit almost any application. This series of Microprocessor temperature controllers are equipped with a Lexan© membrane faceplate to provide a frontal IP54 rating.
Featuring self-tuning, auto-tuning soft-start and bumpless transfer, the 1000 series controllers are quick and easy to commission into a control system with simplistic maintenance processes as well as being easy to install into a standard 1/8 DIN unit.
The large format LED read out features two rows of green 14mm characters to clearly display temperature and control read outs. The IP54 rated facia also features three control keys, a single function key along with a raise and lower key for program controlling.
Gefran Series 400, 600, 650, 1000, 1200 & 1250
Informatii despre stoc temporar indisponibile
€ 648,53
€ 648,53 Buc. (fara TVA)
€ 784,72
€ 784,72 Buc. (cu TVA)
1
€ 648,53
€ 648,53 Buc. (fara TVA)
€ 784,72
€ 784,72 Buc. (cu TVA)
Informatii despre stoc temporar indisponibile
1
| Cantitate | Pret unitar |
|---|---|
| 1 - 4 | € 648,53 |
| 5 - 9 | € 604,46 |
| 10 - 24 | € 567,16 |
| 25 - 49 | € 530,42 |
| 50+ | € 494,33 |
