Schaffner, FN2020 10A 250 V ac/dc 400Hz, Chassis Mount EMI Filter, Fast-On, Single Phase
Documente tehnice
Specificatii
Marca
SchaffnerMaximum Current Rating
10A
Maximum Voltage Rating
250 V ac/dc
Montare
Chassis Mount
Terminal
Fast-On
Number of Phases
1
Serie
FN2020
Number of Stages
Single Stage
Operating Frequency
400Hz
Lungime
64mm
Adancime
35mm
Inaltime
29.3mm
Capacitate
4.7 nF, 150nF
Dimensiuni
64 x 35 x 29.3mm
Inductanta
800 μH
Temperatura minima de lucru
-25°C
Leakage Current
0.74 mA
Temperatura maxima de lucru
+100°C
Rezistenta
1MΩ
Power Loss
2.9W
Detalii produs
FN2020 Series
FN2020 filters are designed for easy and fast chassis mounting and are also avaialble as B versions, the Medical option and A version the Safety option. All FN2020 filters provide a general purpose attenuation performance, based on chokes with high saturation resistance and excellent thermal behaviour.
Approvals
UL recognised component, CSA certified, VDE
€ 17,11
€ 17,11 Buc. (fara TVA)
€ 20,36
€ 20,36 Buc. (cu TVA)
1
€ 17,11
€ 17,11 Buc. (fara TVA)
€ 20,36
€ 20,36 Buc. (cu TVA)
1
Informatii indisponibile despre stoc
Incercati din nou mai tarziu
| Cantitate | Pret unitar |
|---|---|
| 1 - 9 | € 17,11 |
| 10 - 24 | € 15,77 |
| 25 - 49 | € 14,61 |
| 50 - 99 | € 13,64 |
| 100+ | € 12,51 |
