RS PRO Inductive Threaded Barrel Proximity Sensor, M30, 38 mm Detection, PNP NO, 10 → 30 V dc

Nr. stoc RS: 206-6167Producator: RS PRONr. articol Distrelec: 30425469
brand-logo

Documente tehnice (Imaginile sunt cu titlu informativ. Va rugam sa consultati specificatiile tehnice.)

Specificatii

Marca

RS Pro

Dimensiune filet

M30

Tehnologie senzor

Inductive

Detection Range

38 mm

Body Style

Threaded Barrel

Output Function

NO

Digital Switching Output Type

PNP

Lungime cablu

2m

Tip conexiune

Pre-Cabled

Tensiunea de alimentare

10 → 30 V dc

Protectie IP

IP67

Lungime

70mm

Timp montare

Non-Flush

Housing Material

Brass Nickel Plated

Maximum dc Voltage

30V

Temperatura minima de lucru

-25°C

Curent de comutare

200 mA

Reverse Polarity Protection

Yes

Temperatura maxima de lucru

+75°C

Switching Frequency

100 Hz

Short Circuit Overload Protection

Yes

Shielding

Unshielded

Maximum Switching Frequency

100Hz

Tara de origine

Hungary

€ 75,86

€ 75,86 Buc. (fara TVA)

€ 91,79

€ 91,79 Buc. (cu TVA)

RS PRO Inductive Threaded Barrel Proximity Sensor, M30, 38 mm Detection, PNP NO, 10 → 30 V dc

€ 75,86

€ 75,86 Buc. (fara TVA)

€ 91,79

€ 91,79 Buc. (cu TVA)

RS PRO Inductive Threaded Barrel Proximity Sensor, M30, 38 mm Detection, PNP NO, 10 → 30 V dc
