Phoenix Contact STEP POWER Switched Mode DIN Rail Power Supply, 85 → 264V ac ac Input, 12V dc dc Output, 3A

Nr. stoc RS: 540-763Producator: Phoenix ContactCod de producator: 2868570
brand-logo

Documente tehnice

Specificatii

Serie

STEP POWER

Tip produs

Switched Mode

Faza electrica

1

AC or DC Input Voltage

ac

Tensiune intrare

85 → 264V ac

AC or DC Output Voltage

dc

Tensiune iesire

12V dc

Curent iesire

3A

Putere

36W

Numar iesiri

1

Dimensiuni

61 x 54 x 90mm

Latime

54mm

Inaltime

90mm

Adancime

55mm

MTBF

1689000h

Load Regulation

±1%

Standarde

CE

Montare

DIN Rail Mount

Ripple And Noise

40mV Pk-Pk

Maximum Temperature

+70°C

Temperatura minima

-25°C

Model

STEP-PS/ 1AC/12DC/3

Efficiency

>85%

Tara de origine

Vietnam

Detalii produs

Phoenix Contact STEP POWER Single Phase Power Supplies (PSU)

The single-phase STEP POWER generation of compact power supply units from Phoenix Contact have a high degree of efficiency and the low standby losses make for high power efficiency. The PSU’s are available with 24 V DC output voltage in various performance classes and overall widths as well as special voltages 5, 12, 15, and 48 V DC.

These PSU's (Power supply units) have been designed more specifically for building automation, however, are not limited to explicitly that use. Low idling and maximum efficiency help to achieve higher energy efficiency. Not to mention, these power supplies have a DIN rail notch took out of the housing to allow you effortless install, on a DIN rail. DIN Rail power supply's are great for cable management, having everything in a single cabinet for consistent maintenance and ease of use.

Approvals

UL/C-UL Recognised (UL 60950), UL/C-UL Listed (UL 508) approved
