Lumberg Automation Right Angle Female 5 way M12 to Right Angle Female 5 way Unterminated Sensor Actuator Cable, 5m
Documente tehnice (Imaginile sunt cu titlu informativ. Va rugam sa consultati specificatiile tehnice.)
Specificatii
Marca
Lumberg AutomationSerie
RKWT
Cross Sectional Area
0.34 mm²
Number of Cores
5
Sheath Material
Polyurethane PUR
Culoare invelis
Orange
Lungime
5m
Conector 1
M12
Conector 1
Right Angle
Conector 1
5
Tip conector 1
Female
Conector 2
Unterminated
Tip conector 2
Female
Conector 2
Right Angle
Conector 2
5
Coding
A
Protejat
Unshielded
Shielding
Unshielded
Curent nominal
4 A
Tensiune
50 V ac, 60 V dc
Protectie IP
IP65, IP67, IP68, IP69K
Temperatura maxima de lucru
+90°C
Diametru exterior
5.5mm
American Wire Gauge
22 AWG
Temperatura de lucru
-40 → +90 °C
Temperatura minima de lucru
-40°C
Oil Resistant
Yes
Insulation material
PVC
Conductor Material
Copper
Minimum Bend Radius
5 x D
Conductor Resistance
10 mO
Standarde
IEC 61076-2-101
Cable Shape
Round
Tara de origine
Germany
Detalii produs
Leads with angled female M12/M8 plug
From Lumberg, these right-angled sensors leads feature a locking nut that assures a high degree of environmental protection and stability when mated. Ideal for use in industrial automation, the leads are available with either an M12 or M8 female plug at one end.
€ 24,43
€ 24,43 Buc. (fara TVA)
€ 29,56
€ 29,56 Buc. (cu TVA)
1
€ 24,43
€ 24,43 Buc. (fara TVA)
€ 29,56
€ 29,56 Buc. (cu TVA)
Informatii despre stoc temporar indisponibile
1
Informatii despre stoc temporar indisponibile
| Cantitate | Pret unitar |
|---|---|
| 1 - 4 | € 24,43 |
| 5 - 24 | € 23,04 |
| 25+ | € 21,66 |
