Documente tehnice
Specificatii
Marca
KEMETCapacitate
33000µF
Tensiune
63V dc
Timp montare
Screw Terminal
Tehnologie
Aluminium Electrolytic
Dimensiuni
66 x 105mm
Inaltime
105mm
Lungime
105mm
Temperatura minima de lucru
-40°C
Diametru
66mm
Temperatura maxima de lucru
+105°C
Durata de viata
13000 h @ +105 °C/63V dc, 8000 h @ +105 °C/63V dc/Ir
Dimensiune celula
ALS40
Curent de ondulare
21.3A
Leakage Current
6 mA
Polarised
Polar
Toleranta
±20%
Rezistenta in serie
8mΩ
Detalii produs
ALS40/41 Series
Kemet ALS40/41 series screw terminal capacitors cover a wide range of case sizes and voltage ratings featuring high ripple currents and long-life performance. These aluminium capacitors are ideally suited for industrial and commercial applications demanding high reliability and long-life expectancy such as frequency converters, uninterruptible power supply (UPS) systems and switch mode power supplies (SMPS).
Standards
AEC-Q200 qualified
Informatii indisponibile despre stoc
Incercati din nou mai tarziu
€ 42,58
Buc. (fara TVA)
€ 50,67
Buc. (cu TVA)
1
€ 42,58
Buc. (fara TVA)
€ 50,67
Buc. (cu TVA)
1
Cumpara in pachete mari
Cantitate | Pret unitar |
---|---|
1 - 4 | € 42,58 |
5 - 9 | € 38,54 |
10 - 24 | € 35,73 |
25 - 49 | € 34,39 |
50+ | € 33,17 |
