Igus chainflex CF140.UL Control Cable, 5 Cores, 0.34 mm², Screened, 25m, Grey PVC Sheath, 22 AWG

Nr. stoc RS: 765-4001Producator: IgusCod de producator: CF140.03.05.UL
brand-logo
Vezi toate produsele din Cabluri de control

Documente tehnice (Imaginile sunt cu titlu informativ. Va rugam sa consultati specificatiile tehnice.)

Specificatii

Marca

Igus

Serie

Chainflex CF140.UL

Number of Cores

5

Cross Sectional Area

0.34 mm²

American Wire Gauge

22 AWG

Conductor Material

Bare Copper

Sheath Material

PVC

Culoare invelis

Grey

Screened/Unscreened

Screened

Armoured

No

Screen Type

Braid

Minimum Bend Radius

7.5 x D

Lungime

25m

Diametru exterior

8mm

Tensiune

300 V

Curent nominal

7 A

Temperatura maxima de lucru

+70°C

Rezistenta la foc

Flame Retardant

Earth Cable

No

Conductor Resistance

57 Ω/km

Temperatura minima de lucru

-5°C

Oil Resistant

No

Cable Shape

Multicore

Insulation material

TPE

Tara de origine

Germany

Detalii produs

Chainflex® PVC Control Cable CF 140

Chainflex® PVC control cable CF 140 is designed for medium load requirements.

Standards

IEC 60332-1-2, CEI 20-35, FT1, VW-1
