Fluke 355 Clamp Meter, 2000A dc, Max Current 2000A ac CAT III 1000V

Nr. stoc RS: 411-970Producator: FlukeCod de producator: FLUKE 355
brand-logo

Documente tehnice

Specificatii

Marca

Fluke

Absolute Maximum AC Current Measurement

2000A ac

Absolute Maximum DC Current Measurement

2000A dc

Absolute Maximum AC Voltage Measurement

600V ac

Absolute Maximum DC Voltage Measurement

1000V dc

Absolute Maximum Resistance Measurement

400kΩ

Model

355

AC Current Measurement Resolution

10mA

DC Current Measurement Resolution

10mA

Best DC Current Accuracy

±(1.5% rdg +5 Digits)

Clamp Meter Type

AC/DC Clamp Meter

Best AC Current Accuracy

±(1.5% rdg +5 Digits)

Best AC Voltage Accuracy

±(1% rdg +5 Digits)

True RMS

Yes

Jaw Capacity Busbars

58mm

Best DC Voltage Accuracy

±(1% rdg +5 Digits)

Functie

AC Current, AC Voltage, Continuity, DC Current, DC Voltage, Frequency, Resistance

Latime

98mm

DC Current Measurement Range

40/400/2000/1400 A

Dimensiuni

300 x 98 x 52mm

Frecventa minima de auto-rezonanta

0°C

Inaltime

52mm

AC Voltage Measurement Resolution

1mV

AC Voltage Measurement Range

4 V, 40 V, 400 V, 600 V

Maximum Conductor Size

58mm

Temperatura maxima de lucru

+50°C

AC Current Measurement Range

40A, 400A, 2000A, 1400 A

Battery Life

100 h

Greutate

814g

Safety Category Level

CAT IV, CAT III

Safety Category Voltage

600 V, 1000V

Battery Type

AA

Safety Category

CAT III 1000 V, CAT IV 600V

Best Resistance Measurement Accuracy

±1.5% +5 Digits

Tip afisare

LCD

Power Source

Battery

Lungime

300mm

Rezistenta

100mΩ

DC Voltage Measurement Resolution

1mV

Tara de origine

China

Informatii indisponibile despre stoc

Incercati din nou mai tarziu

Informatii indisponibile despre stoc

€ 1.335,53

Buc. (fara TVA)

€ 1.589,28

Buc. (cu TVA)
