Fluke 289 Handheld Digital Multimeter, True RMS, 10A ac Max, 10A dc Max, 1000V ac Max
Documente tehnice
Specificatii
Marca
FlukeMultimeter Type
Handheld
Model
289
Tip afisare
Digital
Model
289
Functie
AC Current, AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Resistance, Temperature
Absolute Maximum DC Current Measurement
10A dc
Absolute Maximum Resistance Measurement
500MΩ
Absolute Maximum DC Voltage Measurement
1000V dc
Absolute Maximum AC Current Measurement
10A ac
Absolute Maximum AC Voltage Measurement
1000V ac
Absolute Maximum Capacitance Measurement
100mF
Absolute Maximum Temperature Measurement
+1350°C
Connectivity
Infrared
Frecventa maxima
100kHz
DC Current Measurement Resolution
0.01µA dc
AC Current Measurement Resolution
0.01µA ac
DC Voltage Measurement Resolution
1µV dc
AC Voltage Measurement Resolution
1µV ac
Rezistenta
10mΩ
Capacitate
1pF
Temperature Measurement Resolution
0.1°C
Safety Category Level
CAT III, CAT IV
Best AC Current Accuracy
±0.7% + 5 Digits
Latime
102mm
Temperatura maxima de lucru
+55°C
Best DC Voltage Accuracy
±0.025% + 5 Digits
Dimensiuni
60 x 102 x 222mm
Best Temperature Measurement Accuracy
±1% + 1 °C
Best AC Voltage Accuracy
±0.4% + 40 Digits
Best Capacitance Measurement Accuracy
±1% + 5 Digits
Temperatura minima de lucru
-20°C
Inaltime
222mm
Greutate
870.9g
Best DC Current Accuracy
±0.15% + 2 Digits
Safety Category Voltage
600 V, 1000V
Battery Type
AA x 6
Best Resistance Measurement Accuracy
±0.05% + 2 Digits
Lungime
60mm
Tara de origine
United States
Detalii produs
Fluke 289 Digital Multimeters
The Fluke 289 is optimised for industrial and field service professionals involved in the installation and maintenance or support of facilities or critical systems. It is the next generation of high performance industrial logging multimeters. Compatible with Fluke Connect, which is designed to solve complex problems in electronics, plant automation, power distribution and electro-mechanical equipment. The ability to log data and graphically review up to 10000 recorded events and logged readings with on-board TrendCapture. This lets the 289 be your watchdog for systems or processes while you are off doing other jobs.
With the Fluke 289 being Fluke Connect-compatible, you can set it up with the ir3000 FC wireless connector (Sold Separately - RS 811-1385) to communicate with your IOS and Android smart devices. This is through the Fluke Connect mobile app and monitor readings from a remote location or sharing the readings with your team in an instant anytime.
Supplied with
The Fluke 289 comes with:
Manual
6 x AA Batteries
Installed TL71 Silicone Test Leads
Probe Holder
2 x AC72 Alligator Clips
Informatii indisponibile despre stoc
Incercati din nou mai tarziu
€ 1.087,28
Buc. (fara TVA)
€ 1.293,86
Buc. (cu TVA)
1
€ 1.087,28
Buc. (fara TVA)
€ 1.293,86
Buc. (cu TVA)
1
