Festo 2/2 Solenoid Valve - Solenoid/Pilot G 1/2 VZWF Series 24V dc, 1492112
Documente tehnice
Specificatii
Marca
FestoFunctie
2/2
Conexiune
G 1/2
Actuation Type
Solenoid/Pilot
Producator
VZWF
Montare
Inline
Solenoid Voltage
24V dc
Montat cu solenoid
Yes
Numar porturi
2
Tip material
Brass
Solenoid Power Consumption
11W
Presiune minima de operare
0bar
Frecventa minima de auto-rezonanta
-10°C
Temperatura maxima de lucru
+35°C
Presiune maxima de operare
10bar
Dimensiune filet
1/2in
Configuration
2-Position, 2 Port
Number of Positions
2
Filet standard
G
Caracteristici speciale
Forced Lifting of the Valve Diaphragm
Tara de origine
Germany
Detalii produs
VZWF Series Solenoid Valves
A force pilot operated solenoid valve that can be used with water, air, and neutral media. The VZVF series of valves uses relatively small solenoids to control high pressures with large nominal diameters. Actuation is supported by the pressure of the medium. They can switch at pressures as low as 0 bar and close automatically in the case of a pressure loss in the circuit. Operating pressure ranges from 0 bar to 10 bar, depending on coils used and nominal diameter.
Informatii indisponibile despre stoc
Incercati din nou mai tarziu
€ 103,39
Buc. (fara TVA)
€ 123,03
Buc. (cu TVA)
1
€ 103,39
Buc. (fara TVA)
€ 123,03
Buc. (cu TVA)
1
Cumpara in pachete mari
| Cantitate | Pret unitar |
|---|---|
| 1 - 4 | € 103,39 |
| 5+ | € 95,58 |
