Documente tehnice
Specificatii
Marca
RecomTensiune iesire
12V dc
Curent iesire
5A
Putere
60W
Numar iesiri
1
Tensiune intrare
127 → 370 V dc, 90 → 265 V ac
Montare
Chassis Mount
Tip pachet
Open Frame
Lungime
101.6mm
Latime
50.8mm
Adancime
30mm
Efficiency
83%
Temperatura minima
-20°C
Greutate
145g
Maximum Temperature
+70°C
Tara de origine
China
Detalii produs
Recom 60W, Open Frame,Switch Mode AC-DC Converter, RAC60 Series
The Recom RAC60/OF series of open frame AC-DC converters have a universal AC input of 90-265Vac and trimmable DC outputs to compensate for voltage drops on the output connections. The DC outputs of these open frame class II power supplies are also fully protected. The RAC60/OF series of regulated converters are CB, UL, CE certified and ErP conform. Applications of these switch mode power supplies include industry controls, test and measurements systems and energy efficient products.
Approvals
CB, UL, CE
Standards
UL-60950-1 2nd, EN-60950-1 2nd
